Retainers
10240-11
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 33.4 mm (1.31 in) |
| Bolt thread | 3/8 - 24 |
| Degrees operation | 90⁰ |
| Length | 84.3 mm (3.32 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10240-1
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 33.4 mm (1.31 in) |
| Bolt thread | 3/8 - 24 |
| Degrees operation | 90⁰ |
| Length | 84.3 mm (3.32 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10232-9
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 70.9 mm (2.79 in) |
| LH/RH to engage | LH |
| Retainer color | Clear |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-8
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 171.9 mm (6.77 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-7
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 171.9 mm (6.77 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-6
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 84.9 mm (3.34 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-5
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 84.9 mm (3.34 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-4
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 157.9 mm (6.22 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-3
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 157.9 mm (6.22 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-2
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 70.9 mm (2.79 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-12
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 157.9 mm (6.22 in) |
| LH/RH to engage | RH |
| Retainer color | Clear |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-11
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 157.9 mm (6.22 in) |
| LH/RH to engage | LH |
| Retainer color | Clear |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-10
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 70.9 mm (2.79 in) |
| LH/RH to engage | RH |
| Retainer color | Clear |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10232-1
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 25.0 mm (0.98 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 70.9 mm (2.79 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Brushed |
| Type | Standard retainer |
..
10231-6
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Brushed |
| Bolt length in panel | 26.8 mm (1.06 in) |
| Bolt thread | 5/16 - 24 |
| Degrees operation | 90⁰ |
| Length | 73.8 mm (2.91 in) |
| LH/RH to engage | RH |
| Retainer color | Violet |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10231-5
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Brushed |
| Bolt length in panel | 26.8 mm (1.06 in) |
| Bolt thread | 5/16 - 24 |
| Degrees operation | 90⁰ |
| Length | 73.8 mm (2.91 in) |
| LH/RH to engage | LH |
| Retainer color | Violet |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10231-4
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Brushed |
| Bolt length in panel | 26.8 mm (1.06 in) |
| Bolt thread | 5/16 - 24 |
| Degrees operation | 90⁰ |
| Length | 127.0 mm (5.00 in) |
| LH/RH to engage | RH and LH |
| Retainer color | Violet |
| Retainer finish | Polished |
| Type | Butterfly retainer (dual) |
..
10227-9
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Blasted |
| Bolt length in panel | 75.2 mm (2.96 in) |
| Bolt thread | 7/16 - 20 |
| Degrees operation | 50⁰ + 90⁰ |
| Length | 100.0 mm (3.94 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-8
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Blasted |
| Bolt length in panel | 76.7 mm (3.02 in) |
| Bolt thread | 7/16 - 20 |
| Degrees operation | 90⁰ |
| Length | 81.5 mm (3.21 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-7
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Blasted |
| Bolt length in panel | 76.7 mm (3.02 in) |
| Bolt thread | 7/16 - 20 |
| Degrees operation | 90⁰ |
| Length | 81.5 mm (3.21 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-6
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Blasted |
| Bolt length in panel | 76.7 mm (3.02 in) |
| Bolt thread | 7/16 - 20 |
| Degrees operation | 90⁰ |
| Length | 136.5 mm (5.37 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-5
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Blasted |
| Bolt length in panel | 76.7 mm (3.02 in) |
| Bolt thread | 7/16 - 20 |
| Degrees operation | 90⁰ |
| Length | 136.5 mm (5.37 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-4
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Blasted |
| Bolt length in panel | 76.7 mm (3.02 in) |
| Bolt thread | 7/16 - 20 |
| Degrees operation | 90⁰ |
| Length | 75.0 mm (2.95 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-18
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 21.0 mm (0.83 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 130.0 mm (5.12 in) |
| LH/RH to engage | RH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
10227-17
| Aeroworks | |
| Bolt head color | Passivate |
| Bolt head finish | Polished |
| Bolt length in panel | 21.0 mm (0.83 in) |
| Bolt thread | 1/2 - 20 |
| Degrees operation | 90⁰ |
| Length | 130.0 mm (5.12 in) |
| LH/RH to engage | LH |
| Retainer color | Candy apple red |
| Retainer finish | Polished |
| Type | Standard retainer |
..
